PEK Tubular Membrane

Category: Tubular membrane modules

1.High-quality non-woven fabric and double-sided welding technology 2. Exclusive PEK material 2.Chemical resistance 2.Superior hydrophilicity 3.Strong anti-pollution ability. 4.As a pretreatment process, the effluent quality is stable with turbidity less than 0.5 NTU and SDI less than 4.

Consult Back

Parameters

Membrane Material		PEK
Cut off		0.2μm	50nm	30nm	10nm
Pure Water Flux	LMH，100kPa	2500	1500	1200	300
Operating Pressure	kPa	-100~1000
Max. Operation T	℃	65
pH-range		0~14
Chlorine Exposure	ppm·h	300000

Keywords:

PLUM

Membrane modules

MBR skid

UF skid

Download attachmen:

Relative Application

SPECIFICATION

Model	Material	Tube ID(mm)	Length(mm)	Module OD (inch)	Housing Material	Membrane area(㎡)
PL-G-6410-F/P	PEK	6mm	4000	10″	FRP/CPVC	69
PL-G-8410-F/P	PEK	8mm	4000	10″	FRP/CPVC	53
PL-G-6310-F/P	PEK	6mm	3000	10″	FRP/CPVC	51
PL-G-8310-F/P	PEK	8mm	3000	10″	FRP/CPVC	40
PL-G-638-F/P	PEK	6mm	3000	8″	FRP/CPVC	34
PL-G-838-F/P	PEK	8mm	3000	8″	FRP/CPVC	28
PL-G-636-F/P	PEK	6mm	3000	6″	FRP/CPVC	19
PL-G-836-F/P	PEK	8mm	3000	6″	FRP/CPVC	15.2
PL-G-634-F	PEK	6mm	3000	4″	FRP	8.4
PL-G-834-F	PEK	8mm	3000	4″	FRP	6.4

Relative Cases

105m³/h RO concentrated wastewater softening

2m³/h waste salt resource utilization

25m³/h pharmaceutical Wastewater softening
